Balboa BP7 4Kw
Description
Description
Balboa BP7
The G4361 is a high‑quality replacement spa circuit board engineered for reliable performance in compatible hot tub control systems. Designed to restore smooth, efficient operation, the G4361 manages essential spa functions including pump control, heater activation, filtration cycles, and temperature regulation. Built with durable, OEM‑grade components, this board provides long‑lasting stability and dependable system management—making it an ideal replacement for aging or malfunctioning electronics. Its straightforward installation and robust design ensure consistent day‑to‑day spa performance
Replaces: 56378-03, 56487-05, 56567, 56901-01
- 115/230v Pump 1 circuit
- 115/230v Pump 2 circuit
- 115/230v Blower circuit
- 115/230v Ozone circuit
- 115/230v Circ Pump circuit (30GPM minimum)
- 1.4/5.5kW heater
- 12v spa light circuit
- Patented M7™ technology
- Component cords included
- Control panel included
- US & Canadian safety approvals
The BP family of Hot Tub Control Systems were designed using Balboa's patented M7™ temperature and flow sensor technology and a new universal control platform. The systems have a plastic enclosure to eliminate water intrusion. Connectors are built onto the circuit board minimizing wires and simplifying service. The different models have controls for a single two-speed pump or an additional blower or pump. All models feature a convertible 115/230v power supply, a 1.4/4.0kW heater and can support mini, duplex, or standard digital control panels.
| Height | Width | Depth |
| 10-9/16" | 12-1/4" | 4-1/2" |
| Number Of Appliances | 2 |
| Manufacturer | Balboa Water Group |
| Model | BP7 |
| Supply Voltage | 115v, 230v |
| Heater Type | Fixed - Bottom |
| Heater Wattage | 1.0kW, 4.0kW |
| Topside | N/A |
| Circ Pump Ready | Optional 115v/230v |
| Auxiliary Topside Ready | Yes |
| Fiber Optic | No |
| Accessory Ready | Yes |
| Wi-Fi Compatible | Yes |
| 50/60 HZ | 60Hz |
